MS1 moisture sensor
Decagon moisture sensors can be used to measure moisture levels in media randing from soils to masonite. It is used in conjunction with the Model SC18 wireless transmitter to integrate into any logging, monitoring, or control system.
Specifications:
| Accuracy |
Mineral Soil:±3% VWC, most mineral soils, up to 8 dS/m ±1-2% VWC with soil specific calibration Rockwool: ±3% VWC, 0.5 to 8 dS/m Potting Soil: ±3% VWC, 3 to 14 dS/m |
| Resolution |
0.1% VWC (mineral soil) 0.25% VWC (rockwool) |
| Range |
up to 0-100% VWC |
| Cable length |
5m |
| Compatable devices |
SC18 |
| Warranty |
One (1) year parts and service
|
Order Online:
|
  |
WSS1 water surface sensor for leak detection
The WSS1 water/ leak detector can be placed in areas to monitor for water from leaks and/or floods. With the Model WSS1 connected to the Model SC18 wireless transmitter, receive immediate notification via software, email and/or text message of a leak detection alarm. System will continuously monitor and provide current status of the WSS1 water/ leak detector on software dashboard. The model SC18 can connect up to four (4) WSS1 leak detectors or combination of our compatible external sensors.
| Measurement |
Water detection - on/off |
| Material |
Surface mount design, Rugged molded polymer case with sensing electrodes |
| Alarms |
Programmable notification via software, text and/or email message |
| Dimensions |
3.0 x 2.0 x .88" (76.2 x 50.8 x 22.35 mm) |
| Cable length |
15' (4.5m) |
| Compatible devices |
SC18 |
| Warranty |
One (1) year parts and service |
